Pleated membrane filter cartridge

Pleated membrane filter cartridge

Features:

The film stack consists of a polypropylene microfiber membrane and a polypropylene non-woven fabric supporting the flow guiding layer. It is a deep filter core folding structure with large membrane filtration area and large flux. Low pressure difference, strong dirt holding capacity and long service life. There are a variety of filtering accuracies to choose from and a wide range of applications. Good chemical compatibility, suitable for filtering strong acids, strong bases and organic solvents. Hot melt welding technology processing, without any chemical glue, no leakage, no secondary pollution.

Application field

1. Reverse osmosis RO system pretreatment

2. Acid, alkali and chemical organic solvent filtration

3. High-purity water pretreatment in semiconductor and electronics industries

4, Mineral water, alcohol, juice filtration

5, Oil field re-injection water filtration

Material construction

1, Filter material: polypropylene (PP)

2. Diversion support layer: polypropylene (PP)

3, Shell / center rod / end cover material: polypropylene (PP)

Operating condition

1, The maximum pressure difference

(1) Forward - 75 PSI (5.1 Bar) @ 20 ° C

(2) Forward - 25 PSI (1.7 Bar) @ 80 ° C

(3) Reverse - 30 PSI (2.0 Bar) @ 25 ° C

2, Filter replacement recommended pressure difference @1.5 Bar-2.0Bar

3, The maximum working temperature: 80 ° C

4, Sterilization and disinfection: 121 ° C online steam sterilization, each 20 minutes, available 5 times, 85 ° C -95 ° C hot water disinfection

Standard sizes

1. Filtration area: 0.5m2/10′′

2, outer diameter: 69mm

3. Nominal length: 5′′, 10′′, 20′′, 30′′, 40′′

4. Nominal accuracy (unit: um): 0.1, 0.2, 0.45, 0.65, 1, 3, 5...............

Model / ordering information

Model

Filtration accuracy

End cap

Sealing material

Nominal size

PPL-PP microporous membrane

010:0.1um   020:0.2um   045:0.45um   100:1um   300:3um............H10: 10um

CODE-0 flat pressure double opening

CODE-7 226/winged tail

CODE-8 222/winged tail

E-ethylene propylene diene rubber

N-J nitrile rubber    S-silicone rubber   V-fluoro rubber

5:5′′ 10:10′′ 20:20′′ 30:30′′ 40:40′′

Interface form

1, 215, 220, 222, 226, threaded M30, threaded M36, etc.

2, fin type, flat head type, triangular fin type, flat type
